Net Information

What's in a Katchakid net system.

Safety is #1, so every component of a Katchakid net system is designed with longevity and quality in mind.

Annotated diagram of a Katchakid pool safety net system

The complete system

Each DIY kit combines custom-sized netting, a Central Tension System, anchors and fasteners matched to your deck, a tensioner and a storage roller.

  • High-density, UV-stabilized netting in 3 colors
  • Central Tension System with 12–16 pulleys
  • Marine-grade brass, nylon and 316 stainless hardware
  • Hand Tensioner included; EZ-Close upgrade available
  • EZ-Off storage roller

Netting

Available in Black, Blue or Sand/Tan.

Katchakid net mesh in Ocean Blue, Jet Black and Desert Sand

Pool mesh material

4mm & 5mm high-density polyethylene (m) fiber, saturated with non-substituted aliphatic hydrocarbons and chemically treated with stabilized inhibitors. Machine-formed, heat-stented knots.

  • Superior tensile strength
  • Maximum UV deterioration resistance
  • Waterproof; resilient to bases, acids & solvents
  • Guaranteed accuracy and uniformity of mesh size and knot tightness

Anchors & fasteners

Flush-style anchors are the most widely used and are best for flat surfaces from concrete to slate.

Brass anchors

Durable marine-grade brass gives a harder surface for increased wear resistance.

Nylon anchors

Injection-molded nylon in Cream, Gray or Terracotta. Color coordinated, corrosion resistant, with good adhesion and bonding properties.

Vertical mounts (pad-eye)

Grade 316 stainless steel pad-eye with a round cross section. The round body prevents rope chafe. Maximum corrosion resistance and durability.

Vertical connectors (wall anchor)

Grade 316 stainless steel spring clip for maximum corrosion resistance and durability.

Fasteners (net hooks)

Grade 316 stainless steel, precision engineered. A conical head ensures reliable performance and tangle resistance.

Matched to your deck

Tell us your deck or edge surface on the quote form and we'll confirm the right anchors. Quote form →

Central Tension System

Adjustable from tight to very tight, and designed so it cannot be removed by most children under 12.

The CTS uses a series of pulleys set in a circle that open and close to control the net's tension. The correct configuration and size of the CTS, with the right number of pulleys, determines a pool net's efficiency. The Katchakid uses an average of 12 to 16 pulleys per net.

CTS pulleys

Modified nylon compound, injection molded with an internal steel shaft. Buoyant, resists oils and solvents, corrosion resistant, high load / low friction, prevents rope slippage.

Central tension rope

Polyester fiber with a braided exterior and a continuous multifilament core. Meets MIL-DTL-24677B. Good abrasion resistance, 3,400 lb breaking tenacity, high strength with low elastic elongation.

Tensioners & storage

Katchakid Hand Tensioner

Hand Tensioner (included)

The easy-grip standard tensioner with injection-molded components and a die-cast anti-friction mechanism. Pulls up to 250 lbs of tension for fast removal and replacement. Lightweight, quick, easy to use and store.

Katchakid EZ-Close Tensioner

EZ-Close Tensioner (upgrade)

A stamped carbon steel frame with efficient gear ratios, full-length drum bearings and an oil-impregnated shaft bushing. Pulls at 900 lbs with minimal strain: no pulling or tugging, compact, and corrosion resistant.

EZ-Off Roller

A lightweight, portable storage roller made from high-quality rigid PVC (W.P. PSI 370, ASTM D1785 compliant). In general it takes 3–5 minutes to remove and 5–8 minutes to replace the net on an average pool, and the roller lets you store the net until it's needed.

Remember: all pool safety barriers, covers and gates are supplementary safety aids, not a substitute for the constant, undivided supervision of an adult. Covers can never replace supervision or guarantee against drowning or other accidents. Always replace your cover after swimming. Multiple layers of protection offer the best protection, and children under 5 are most at risk.

Ready for your kit?

Send us your measurements and photos for a custom DIY net kit quote.
